| 型號 Model | FXL-915 | F2XL-915 | FXL-1115 | F2XL-1115 |
|
螺旋體直徑（mm） Spiral Body Diameter |
915 | 915 | 1115 | 1115 |
|
水槽長度（mm） Sink Length |
7585 | 7585 | 9782 | 9782 |
|
給料尺寸（mm） Feeding Size |
≤ 10 | ≤ 10 | ≤ 10 | ≤ 10 |
|
處理能力（t/h） Processing Power |
100 | 200 | 175 | 350 |
|
轉速（r/min) Rotating Speed |
21 | 21 | 17 | 17 |
|
電機功率（kw） Motor Power |
11 | 2*11 | 15 | 2*15 |
|
耗水量（t/h) Water Consumption |
10-80 | 20-160 | 20-150 | 40-300 |
|
外形尺寸（mm） Dimensions |
8500*2810*3600 | 8420*3760*396 | 1078*3980*4170 | 10970*5250*4720 |
|
重量（t） Weight |
6.27 | 11.11 | 10.18 | 17.94 |
